- AcePro-CE56-1
- AcePro Wallplate HDMI/VGA HDBaseT Kit
■ HDBaseT extender with wall plate designed Transmitter and Control Panel and wall mounting Receiver box ■ Allows you to switch freely between your HDMI and VGA input device via push button ■ IR receiver on the Control Panel controls a projector or other display device at the remote location ■ Output resolutions: 1024x768, 1280x720, 1280x800, 1360x768, 1600x1200, 1920x1080, or 1920x1200 ■ Supports transmission distance up to 98ft (30m) at 1920x1200 @60Hz over CAT cabling ■ Supports PoC to power the Transmitter, Control Panel and Receiver via a single power adapter connected to the Receiver ■ Easy-to-use Control Panel for convenient device control in showrooms, classrooms, and boardrooms ■ Supports IR learning of the display device's (projector, TV, etc.) IR remote for easy device control at the Control Panel
Eigenschaften
Wallplate Design
HDBaseT extender with wall plate designed Transmitter and Control Panel and wall mounting Receiver box
Switch Between HDMI And VGA Input Via Push Button
Allows you to switch freely between your HDMI and VGA input device via push button
IR Receiver
IR receiver on the Control Panel controls a projector or other display device at the remote location
Supports Resolutions Up To 1920x1200
Output resolutions: 1024x768, 1280x720, 1280x800, 1360x768, 1600x1200, 1920x1080, or 1920x1200
Supports Up To 98ft Over CAT Cabling
Supports transmission distance up to 98ft (30m) at 1920x1200 @60Hz over CAT cabling
Supports POC
Supports PoC to power the Transmitter, Control Panel and Receiver via a single power adapter connected to the Receiver
Convenient Device Control
Easy-to-use Control Panel for convenient device control in showrooms, classrooms, and boardrooms
Supports IR Learning Of The Display Device
Supports IR learning of the display device's (projector, TV, etc.) IR remote for easy device control at the Control Panel
Spezifikation
Supports HDMI 1.4 and HDCP 1.4
Output resolution: 1024x768, 1280x720, 1280x800, 1360x768, 1600x1200, 1920x1080, or 1920x1200
Bandwidth: 10.2Gbps
Switch freely between HDMI and VGA signal input
Supports MIC input
Amplifier output: 2x20Watt @ 4ohms
Customizable control panel supports IR learning for convenient device control
Supports UPNP
Product:
Transmitting unit (TX):
■ Dimensions: 4.14" (W) x 3.50" (H) x 1.74" (D)
■ Weight: 0.53 lbs lbs
■ Connectors:
■ 1x 19-pin HDMI, Type A, Female, Input
■ 1x 15-pin VGA, D-Sub, Female, Input
■ 1x 1x 3.5mm, Stereo Audio, Input
■ 1x 8-pin, RJ45, HDBaseT/PoC output
■ 1x 8-pin, RJ45, Connect to Control Panel Power/RS-232
■ 1x Blue-Backlight button, Source select
■ 1x 4-pin USB Type-B, Female, Connect to PC
■ 1x 5-pin Micro USB, Firmware update
■ 1x Reset button
Receiving unit (RX):
■ Dimensions: 9.84" (W) x 1.22" (H) x 5.12" (D)
■ Weight: 3.31 lbs
■ Connectors:
■ 1x 19-pin HDMI, Type A, Female, Output
■ 1x 8-pin, RJ45, HDBaseT/PoC input
■ 1x 8-pin, RJ45, TCP/IP Network
■ 1x 4-pin USB, Touchscreen
■ 1x 3.5mm jack, IR Out
■ 1x 3-pin, RS-232, Phoenix connector
■ 1x 2-pin, Remote Mute, Phoenix connector
■ 1x 3-pin, Audio Line out, Phoenix connector
■ 1x 3-pin, MIC input, Phoenix connector
■ 1x 4-pin, 2x20Watt @4ohms, Power connector
■ 1x Power jack, DC 24V input
Control Panel:
■ Dimensions: 4.49" (W) x 2.76" (H) x 1.34" (D)
■ Weight: 0.31 lbs
■ Connectors:
■ 1x 4-pin USB Type-A, U-disk configuration data
■ 1x 8-pin, RJ45, Connect to Transmitter Power/RS-232
■ 1x Volume Knob, volume control
■ 4x Blue-backlight button, ON / HDMI / VGA / OFF control
■ 1x IR sensor, receive IR signal via IR remote
■ 1x 3-Pin, RS-232, Phoenix connector
■ 1x 5-pin, Micro USB, Firmware update
Power adapter:
■ Input: 100-240VAC, 50/60 Hz
■ Output: DC 24V/2.71A
Environmental conditions:
■ Operating temperature: 32 to 122 degrees F
■ Storage temperature: 14 to 158 degrees F
■ Relative humidity: 10 to 90% RH (non-condensing)
Certifications/Standards: FCC, CE, RoHS
Warranty: 3 year limited
Country of origin: China
