- new | AVLT-CH41
- 16-Port Industrial USB-C PD Charging Station - 600W - 30W per port - UL Certification
Industrial grade power charging station adds 16 USB-C charging ports, 30W per port, PD 2.0 & 3.0 for 5V/3A, 9V/3A and 12V/2.5A, Over Current, Over Voltage, Over Heating, Short Circut, ESD Protection, Metal Housing, UL Certification
- $359.99
Highlights
- Easily and quickly charge up to 16 USB-C devices such as iPhone/iPad, Tablet, Smart Phone, Mobile device and each port up to 30W charging power
- Support Power Delivery 2.0 & 3.0 for 5V/3A, 9V/3A and 12V/2.5A charging specification
- Industrial grade & built-in 24V 600W (Meanwell Brand) power adapter with UL certification to keep the safe charges
- Power switch conserves energy when not in use, built-in LED provides easy recognition of power status
- Protection and Reliability for Over-voltage, input under voltage, output short circuit, output over current, system over temperature
- Enables to turn on/off the fans automatically according to the temperature setup
- Fully heat dissipating and durable metal housing rack mountable into a standard 19-inch rack
- Compatible with Apple iPhone 14/13/12/11/X, iPhone 8, iPhone 8 Plus, Samsung Galaxy Note 8, S8, S8 plus and more, Tablets/ Laptop for Apple iPad, MacBook 12-inch, MacBook Air/Pro and more USB-C devices. This is an excellent choice for charging USB-C products
Specification
- Chipset: IP6520T
- Internal Power Supply: 600W–24V Meanwell switching power supply
- Input:
- Input Voltage: 110VAC/220VAC select by Switch
- Frequency: 50Hz / 60Hz
- Input Current: 12A/115VAC, 7.5V/230VAC
- Output
- USB Port: 16 x USB-C, Female
- PD output power: 30W (5V/3A, 9V/3A, 12V/2.5A)
- Efficiency: VIN=24V, VOUT=5V/3A, Conversion Efficiency is 92%
- USB-C Protocol
- Support 5V / 9V / 12V Voltage output
- Support PD 2.0 / PD 3.0
- PPS support 3 to 11V, 20mV/step Voltage output
- Output specification
- Support USB-C PD output
- Support BC 1.2_DCP, Apple, Samsung protocol
- Support Qualcomm QC2.0 / QC3.0
- Support MTK PE+1.1 and MTK PE+2.0
- Support Fast Charging protocol FCP and AFC (Max 12V)
- LED indicators:
- Charging in progress: RED color
- Power On or Fully charged: GREEN color
- Output overcurrent protection: output >3.5 to 3.9A, USB port current output automatic disconnect
- Output overvoltage protection: When the output terminal voltage>16V or more due to an accidental cause, the TVS discharge on the terminal circuit causes the input circuit fuse to open, cutting off power to the circuit and thus protecting the equipment at this port
- Product:
- Dimensions: 17.32"(W) x 2.24"(H) x 8.07"(D)
- Weight: 6.38 lbs
- Color: Black
- Housing: Metal housing with standard 19 inch rack mounting
- Connectors:
- 1x AC Power Jack
- 1x Power Switch
- 16x USB Type-C, Female, USB device connection
- Unit Package:
- Dimensions: 22.32" (W) x 3.27" (H) x 9.72" (D)
- Weight: 7.44 lbs
- Environmental conditions:
- Operating temperature: 14 to 131 degrees F
- Storage temperature: -4 to 158 degrees F
- Relative humidity: 20% to 90% RH (non-condensing)
- Working Altitude: Less than 2km
- Certifications/Standards: FCC, CE, RoHS, UL
- UL E183223
- Country of origin: Engineered in USA , Manufactured in China
