• AVLAB 4-Port SATA Hybrid PCIe, 6Gbps, RAID, i/e Serial ATA, Dual Profile Bracket
• AVLAB-SC03-1
• ■ Add 4 SATA 6Gb/s channels to your PCIe system
  ■ Flexible port configurations:
  4 internal
  2 external and 2 internal
  1 external and 3 internal
  ■ Built-in the latest breakthrough Hybrid HyperDuo tiering technology
  ■ An economical way to enable SSD performance at 1/3 the cost
  Note: HyperDuo automatic storage tiering is only compatible with Windows XP, Vista, 7 and 8. This feature is not fully supported in the Server OSes
  ■ Improve system performance to reduce boot up time of system with demanding applications such as graphic editing tools, gaming, media player and more
  ■ Allow large data to be stored on the high capacity HDDs for cost saving
  ■ Fully automated HyperDuo tiering technology, no need to monitor hot/cold data manually
  ■ HyperDuo mode supports Safe mode and Capacity mode
  ■ Supports Port Multiplier FIS-based and Native Command Queuing (NCQ)
  Note: Only one Port Multiplier is supported at any one time. Supports up to 4 drives connected via Port Multiplier plus 3 single drives for 7 drives total
  ■ Hardware RAID (RAID 0, 1, 10) to offload the host CPU for max performance
  ■ Inbox drivers enable users to take advantage of OS commands like TRIM to extend the life of SSDs for maximum durability
  ■ Installs in standard height or low profile chassis with included brackets
  ■ Works with the latest 6Gb/s SATA HDDs and backwards compatible with 3Gb/s and 1.5Gb/s HDDs


• AVLAB 2-Port SATA II PCIe, 3Gbps, Internal Serial ATA, Dual Profile Bracket
• AVLAB-SC04-1
• ■ PCI Express 1-lane (x1) SATA II adapter works with PCI Express slots with different lane width
  ■ Installs in any available PCI Express slot
  ■ Supports two independent Serial ATA channels
  ■ Dual profile design to work with full height and low profile chassis with included brackets


• AVLAB Dual Port SATA II PCIe, 3Gbps, Internal Serial ATA, Dual Profile Bracket
• AVLAB-SC05-1
• ■ PCI Express 1-lane (x1) SATA II adapter works with PCI Express slots with different lane width
  ■ Installs in any available PCI Express slot
  ■ Supports two independent Serial ATA channels
  ■ Spare enhanced low profile bracket is included to work in low profile chassis


• AcePro Mini DisplayPort 1.2 to HDMI Adapter- 4K 60Hz, Active Adapter
• AcePro-CB02-1
• ■ Transmits high definition video resolutions up to 4Kx2K/60Hz with 24-bit color and up to 8-channel audio
  ■ Supports RGB up to 12-bit and YCbCr in 4:4:4/4:2:2 pixel formats
  ■ Supports AMD Eyefinity with SLS (Single Large Surface) video wall mode (requires connecting multiple adapters) allows combining multiple monitors into one large display for panoramic display
  ■ Compatible with both HDCP 1.4 and HDCP 2.2 content protection
  ■ Plug-n-play with no driver installation or external power source required
  ■ Compact and lightweight design offers great portability while on-the-go

• AcePro HDMI to DisplayPort 4K Ultra HD Converter, 4K 30Hz, USB Powered, 7.1CH Audio
• AcePro-CE31-1
• ■ Easily connect a DisplayPort monitor to a HDMI equipped notebook, desktop or other HDMI source device.
  Note: This is NOT a bi-directional adapter. DO NOT use for Displayport to HDMI conversion
  ■ Compliant with DisplayPort specification v1.2, supporting 1.62, 2.7Gbps and 5.4Gbps
  ■ Compliant with HDMI 1.4a specification, link rate up to 2.97Gbps/data pair
  ■ Supports video resolution up to 1920x1080 @60Hz and 4Kx2K @30Hz
  ■ Supports 7.1-ch audio, sample rate up to 192kHz
  ■ USB-Powered and Plug and play, no software required

• AVLAB Mini DisplayPort 1.2 to 3-in-1 MultiPort Video Adapter - 4K HDMI, DVI, VGA, Converter
• AVLAB-CB42-1
• ■ Simply connects the Mini DisplayPort output of tablet or laptop computer to either a HDMI, DVI or VGA equipped display device
  ■ Works with one connected output at a time
  ■ 3-in-1 converter solution expands the compatibility between Mini DisplayPort and most mainstream displays without requiring an additional adapter
  ■ Supports DisplayPort 1.2 protocols includes 48-bit color depth, high bite rate (up to 21.6 Gbps) and maximum video resolution up to 4Kx2K (30Hz) on HDMI output
  ■ Compact and lightweight design makes it a perfect solution to use at home, in the office, or on the road
  ■ No driver installation required
  ■ Supports audio out through HDMI connection only
  ■ Bus-powered, no external power source required

• AVLAB Mini DisplayPort to VGA Adapter, 1920x1080
• AVLAB-CB43-1
• ■ Designed for connecting the latest Mini DisplayPort equipped computers to work with analog VGA equipped monitors, providing optimal video quality
  ■ Compatible with Mini DisplayPort equipped Mac® computers, including MacBook®, MacBook Air®, MacBook Pro® and others
  ■ Compliant with Mini DisplayPort 1.1a (both 1.62 and 2.7 Gbps) specifications
  ■ Supports full Mini DisplayPort link tracking
  ■ Display modes:
  PC VGA, SVGA, XGA, SXGA and UXGA display modes
  HDTV: 480i, 576i, 480p, 576p, 1080i and 1080p
  ■ Supports HDCP (High-bandwidth Digital Content Protection) on HDCP compliant VGA displays

• AVLAB DisplayPort (M) to HDMI (F) Adapter, 1920x1080
• AVLAB-CB44-1
• ■ "Dongle" style DisplayPort to HDMI converter
  ■ Designed for connecting the latest DisplayPort equipped computer systems to HDMI equipped monitors and televisions, providing optimal video quality
  ■ Compliant with DisplayPort 1.1 (both 1.62 and 2.7 Gbps) specifications
  ■ Display modes:
  PC VGA, SVGA, XGA, SXGA, and UXGA display modes (up to 1900 x 1200)
  HDTV: 480i, 576i, 480p, 576p, 1080i and 1080p
  ■ Supports digital audio (system's DisplayPort must support audio)
  ■ Supports HDCP (High-bandwidth Digital Content Protection) on HDCP compliant HDMI displays
  ■ Latching DisplayPort connector to prevent accidental disconnection
  ■ Video bandwidth: Up to 2.25 Gbps

• AVLAB DisplayPort to HDMI Adapter, 1920x1080
• AVLAB-CB45-1
• ■ Designed for connecting the DisplayPort equipped computer systems to HDMI equipped televisions and monitors to provide optimal video and audio quality
  ■ Triple-shielded 9.5” (24cm) cable with 20-pin DisplayPort male to 19-pin HDMI female connectors
  ■ PVC jacket for maximum audio/video performance with virtually no signal loss
  ■ Compliant with DisplayPort 1.1 (both 1.62 and 2.7 Gb/s) and HDMI 1.3a (up to 2.25 Gb/s) specifications
  ■ Supports HDCP (High-bandwidth Digital Content Protection)

• AVLAB DisplayPort to DVI Adapter, 1920x1080
• AVLAB-CB46-1
• ■ Designed for connecting DisplayPort equipped computer systems to DVI-D Single Link equipped monitors to provide optimal video quality
  ■ Triple-shielded cable with PVC jacket for maximum video performance and prevention of signal loss
  ■ Features 20-pin DisplayPort (male) to 29-pin DVI-D (female) connectors
  ■ Compliant with DisplayPort 1.1a (both 1.62 and 2.7 Gbps) and DVI 1.0 (up to 1.65 Gbps) specifications
  ■ Supports HDCP (High-bandwidth Digital Content Protection)

• AVLAB DisplayPort to VGA Adapter, 1920x1080
• AVLAB-CB47-1
• ■ Designed for connecting the DisplayPort equipped computer systems to analog VGA equipped monitors to provide optimal video quality
  ■ Triple-shielded cable with PVC jacket for maximum video performance and prevention of signal loss
  ■ Features 20-pin DisplayPort (male) to 15-pin VGA (female) connectors
  ■ Delivers video bandwidth of up to 5.7 Gb/s and offers up to 5.4 Gb/s over two lanes
  ■ Supports HDTV resolutions of 480i, 576i, 480p, 576p, 1080i, and 1080p, PC VGA, SVGA, XGA, SXGA and UXGA display modes
  ■ Compliant with DisplayPort 1.1 and supports HDCP (High-bandwidth Digital Content Protection) on HDCP compliant VGA displays

• AVLAB DisplayPort 1.2 to 3-Port HDMI MST Splitter, 4K 30Hz, Aluminum, woven braided cable, Multiple Display
• AVLAB-CE05-1
• ■ Boost your productivity by connecting three HDMI displays to single DisplayPort output with Multi-Stream Transport (MST) technology
  ■ Provides multiple display modes for various applications such as Mirror* mode same content on each display, Extended mode with individual content on each display, and Video Wall mode** which combines multiple monitors to use as one large display
  Note: *Mirror mode using a NVIDIA Surround technology graphics adapter is limited to 2 displays. **Video Wall mode requires either a AMD Eyefinity, Intel, or NVIDIA Surround technology graphics adapter
  ■ Supports UHD video resolutions up to 3840x2160 @30Hz (4K) and 7.1-ch surround audio
  ■ Compatible with DisplayPort 1.2 MST graphics adapters such as AMD Eyefinity, NVIDIA Surround technology, or various Intel Graphics
  ■ Plug-n-play, hassle-free set up without complicated hardware or driver installation
  ■ Premium aluminum housing reduces outside interference and provides optimal video quality
  ■ Built-in woven braided DisplayPort cable for enhanced durability

• AVLAB DisplayPort 1.2 to 3-Port DisplayPort MST Splitter, 4K 30Hz, Aluminum, woven braided cable, Multiple Display
• AVLAB-CE06-1
• ■ Boost your productivity by connecting three DisplayPort displays to single DisplayPort output with Multi-Stream Transport (MST) technology
  ■ Provides multiple display modes for various applications such as Mirror mode* same content on each display, Extended mode with individual content on each display, and Panoramic Video Wall mode** which combines multiple monitors to use as one large display
  Note: *Mirror mode using a NVIDIA Surround technology graphics adapter is limited to 2 displays. **Video Wall mode requires either a AMD Eyefinity, Intel, or NVIDIA Surround technology graphics adapter
  ■ Supports UHD video resolutions up to 3840x2160 @30Hz (4Kx2K) and 7.1-ch surround audio
  ■ Compatible with DisplayPort 1.2 with MST graphics cards with AMD Eyefinity or NVIDIA Surround technology
  ■ Plug-n-play, hassle-free set up without complicated hardware or driver installation
  ■ Premium aluminum housing decreases surrounding interference and provides optimal video quality. Built-in woven braided cable for enhanced durability

• AVLAB DisplayPort 1.2 to 4-Port DisplayPort MST Splitter, 4K 30Hz, Aluminum, woven braided cable, Multiple Display
• AVLAB-CE07-1
• ■ Boost your productivity by connecting three DisplayPort displays to single DisplayPort output with Multi-Stream Transport (MST) technology
  ■ Provides multiple display modes for various applications such as Mirror mode* same content on each display, Extended mode with individual content on each display, and Panoramic Video Wall mode** which combines multiple monitors to use as one large display
  Note: *Mirror mode using a NVIDIA Surround technology graphics adapter is limited to 2 displays. **Video Wall mode requires either a AMD Eyefinity, Intel, or NVIDIA Surround technology graphics adapter
  ■ Supports UHD video resolutions up to 3840x2160 @30Hz (4Kx2K) and 7.1-ch surround audio
  ■ Compatible with DisplayPort 1.2 with MST graphics cards with AMD Eyefinity or NVIDIA Surround technology
  ■ Plug-n-play, hassle-free set up without complicated hardware or driver installation
  ■ Premium aluminum housing decreases surrounding interference and provides optimal video quality. Built-in woven braided cable for enhanced durability ■ Embedded woven braided DisplayPort cable for enhanced durability

• AcePro DisplayPort 1.2 to HDMI Adapter - 4K 60Hz, Active Adapter
• AcePro-CB01-1
• ■ Transmits high definition video resolutions up to 4Kx2K/60Hz with 24-bit color and up to 8-channel audio
  ■ Supports RGB up to 12-bit and YCbCr in 4:4:4/4:2:2 pixel formats
  ■ Supports AMD Eyefinity with SLS (Single Large Surface) video wall mode (requires connecting multiple adapters) allows combining multiple monitors into one large display for panoramic display
  ■ Compatible with both HDCP 1.4 and HDCP 2.2 content protection
  ■ Plug-n-play with no driver installation or external power source required
  ■ Latching DisplayPort connector provides secure connection
  ■ Compact and lightweight design offers great portability while on-the-go

• AVLAB Single Port Gigabit Ethernet PCIe Card, Dual Profile Bracket
• AVLAB-GE01-1
• ■ Adds a high-speed Gigabit Ethernet port into PCI Express (PCIe) enabled computers
  ■ Supports crossover detection & auto-correction
  ■ Supports full duplex mode that doubles the network connection speed
  ■ Supports Wake On LAN (WOL) power management
  ■ Checksum and Segmentation Task-offload reduce CPU workloads for enhanced system response and network scalability
  ■ Automatic MDI/MDIX crossover at all speeds
  ■ Supports Flow Control, Layer 2 Priority Queuing, VLAN Tang and Jumbo Frames
  ■ LEDs indicate the Link/Activity status and 10/100/1000 Mbps
  ■ Easy plug-n-play installation
  ■ Works in any available PCI Express slot
  ■ Dual Profile design to work with standard height and low profile chassis


• AVLAB Dual Port Gigabit Ethernet PCIe Card, Dual Profile Bracket
• AVLAB-GE02-1
• ■ Adds two high-speed Gigabit Ethernet port to PCI Express enabled computers with low profile or standard height chassis
  ■ Supports 10/100/1000 Mb/s data rate auto-negotiation
  ■ Supports full duplex mode that doubles the network connection speed
  ■ Supports Wake On LAN (WOL) power management

• AVLAB Mini-DP Video Dock with USB 3.0 LAN Hub - White, Full-HD 1080p 60Hz, Gigabit, DP/HDMI Video
• AVLAB-US43-1
• ■ Solves your system's connectivity needs by adding two USB 3.0 ports and one Gigabit Ethernet port through one USB 3.0 port
  ■ Supports USB 3.0 data transfer rates up to 5Gbps for smooth and stable performance
  ■ Converts your system's Mini DisplayPort output to either HDMI or DisplayPort output
  ■ Supports triple display modes (Mirror, Extended, Primary) through either HDMI or DisplayPort output to various applications such as presentation or entertainment
  ■ Compact and lightweight design makes it easy-to-carry and the perfect on-the-go gadget
  ■ Compatible with many Mini DisplayPort and USB 3.0 equipped computers, laptops and tablets
  ■ Plug and play, no driver installation and no external power adapter required

• AVLAB Dual Port Gigabit Ethernet PCIe Card - I350-T2, 4-Lane, Dual Profile Bracket
• AVLAB-GE03-1
• ■ Quickly adds two independent Gigabit Ethernet ports through an available PCI Express slot to server or desktop systems
  ■ Intel I350-T2 chipset supports reliable and advanced network connectivity
  ■ Compliant with IEEE 802.3, 802.3u, 802.3ab with full duplex and Wake-on-LAN support
  ■ Features innovative power management including Energy Efficient Ethernet (EEE) and DMA Coalescing to increase efficiency and reduce power consumption
  ■ Fits both standard and low profile system chassis with the included spare low profile bracket


• AVLAB Quad Port Gigabit Ethernet PCIe Card - I350-T4, 4-Lane, Dual Profile Bracket
• AVLAB-GE04-1
• ■ Quickly adds four independent Gigabit Ethernet ports through an available PCI Express slot to server or desktop systems
  ■ Intel I350-T4 chipset supports reliable and advanced network connectivity
  ■ Compliant with IEEE 802.3, 802.3u, 802.3ab with full duplex and Wake-on-LAN support
  ■ Features innovative power management including Energy Efficient Ethernet (EEE) and DMA Coalescing to increase efficiency and reduce power consumption
  ■ Fits both standard and low profile system chassis with the included spare low profile bracket
