■ Allows you to display one HDMI/DisplayPort source signal to up to 4 displays tiled together to form one large screen
■ Easy to layout and modified to fit your applications in digital signage, broadcasting, education and surveillance systems and optimize visual effects
■ Supports HDMI and Mini DisplayPort input from 640x480 to 4Kx2K @60 YUV 4:4:4, interlaced or progressive
■ Image parameters and layouts are automatically saved in flash memory of the device and can be recalled for later use
■ Supports remote control to switch 1x1, 2x2, 1x3 rotate, and 1x4 rotate mode
■ Supports individual propagation delay on each display to have the best visual perception
■ The video wall processor can control by USB, push button, Ethernet, IR remote control and cloud control
■ High quality metal housing with ventilation panels better promote the heat dissipation and system stability during long hours of operation
■ Premium design easily adopts into versatile application environment, mounting brackets included for different installation requirements
■ High quality Coaxial/Toslink S/PDIF Optical bi-directional audio converter allows you to convert Coaxial RCA audio input to Toslink Optical audio output or Toslink Optical audio input to Coaxial RCA audio output
■ Built-in digital audio signal amplifier maintains signal integrity without signal loss
■ Easily switch between input and output direction with the handy built-in selection switches
■ Supports LPCM, AC3, DTS audio, 24-bit audio depth, with sample rate up to 192KHz
■ Sturdy metal enclosure provides durability and minimizes EMI/RF noise interference for long life and dependable performance
■ Plug and play, no software installation required
■ Handy tool to select and switch between 3 Toslink S/PDIF inputs and transmit to 1 Toslink S/PDIF output
■ Built-in digital signal amplifier maintains signal integrity without signal loss
■ Easy S/PDIF source device selection via embedded DIP switches
■ Supports LPCM, AC3, DTS audio, 24-bit audio depth, with sample rate up to 192KHz
■ Sturdy metal enclosure provides durability and minimizes EMI/RF noise interference for long life and dependable performance
■ Plug and play, no software installation required
■ Handy tool to split 1 Toslink S/PDIF digital input into 3 Toslink S/PDIF digital outputs
■ Built-in digital signal amplifier maintains signal integrity without signal loss
■ Supports LPCM, AC3, DTS audio, 24-bit audio depth, with sample rate up to 192KHz
■ Sturdy metal enclosure provides durability and minimizes EMI/RF noise interference for long life and dependable performance
■ Plug and play, no software installation required
■ Supports 2x20 Watts @4 ohms default amplifier output or 1x40 Watts @8 ohms (Bridge Connection)
■ Volume/Bass/Treble control by push buttons with IR remote control or RS232 software control
■ Two stereo audio inputs, switchable by push button, IR remote, or RS232
■ MIC supports balance/unbalance signal and effectively suppresses external noise
■ Ultra low inrush current, no need for power sequencing. This allows multiple Mini Digital Amplifier to be powered on simultaneously without overloading power circuits
■ Anti-static metal case design with efficient convection cooling
■ Extends 1080p HDMI signals up to 394ft (120m) through Belden 1694A RG6 coaxial cable
■ Supports 7.1-channel audio and stereo audio through HDMI signal
■ Supports video resolutions 480i, 576i, 720p, 1080i, and 1080p
■ Bi-directional IR pass-through feature allows you to remotely control the HDMI source device at the display side or control the display at the HDMI source device side
■ High quality durable metal housing with ventilation panels provides excellent heat dissipation to ensure reliable performance and system stability during long hours of operation
■ Modern design with detachable wall mount brackets easily integrates into any installation environment
■ Converts HDMI signal to 3G/HD/SD-SDI in the real time with multi-channel digital audio or high quality analog stereo embedder
■ Supports a wide range of video and audio formats up to 1080p resolution and 7.1 channel audio
■ Supports SDI data rates from 270Mbps up to 2.97Gbps
■ Metal housing provides better RF shielding and heat dissipation to deliver longer operational lifespan
■ Wall-mountable metal housing allows for easy integration in various installation environments
■ Plug & Play - No driver or software installation required
■ Converts one 3G/HD/SD-SDI signal to high quality HDMI video out and analogy stereo audio output
■ Supports a wide range of video and audio formats up to 1080p resolution with multi-channel digital audio
■ Supports SDI data rates from 270Mbps up to 2.97Gbps and HDMI output up to 6.75Gbps
■ Metal housing provides better RF shielding and heat dissipation to safeguard longer operational lifespan
■ Wall-mountable metal housing allows easy integration into various installation environments
■ Plug & Play - No driver or software installation required
■ Extracts high quality Stereo Analog audio and Digital Toslink S/PDIF audio from the incoming HDMI signal without losing any active audio channels
■ Embeds external Stereo Analog audio or Digital S/PDIF (Toslink) audio to the outgoing HDMI signal
■ Supports HDMI Input and Output up to 4K @60Hz (YUV 4:4:4 8-bit), HDR 4K @60Hz (YUV 4:2:0 10-bit)
■ Compatible with HDMI 2.0a and HDCP 2.2
■ Video bandwidth up to 18Gbps
■ Supports CEC bypass and Audio Return Channel (ARC) audio extraction via Toslink
■ EAN Code: 4712896221549
■ HDMI SPLITTER 1 IN 4 OUT - Distributes HDMI video and audio from a single input source to 4 HDMI displays without signal degradation. The 4 EDID modes allows widespread use for showroom, classroom, church, multiple displays events, and duplicating satellite tv signal.
■ Extends USB 2.0 transmission distance up to 264 feet (80 meters) to connect to far away USB devices
■ Connect up to four USB peripheral devices, such as USB printers, USB camera, USB storage devices, USB card-readers, and more
■ Supports USB 1.0 (low-speed), USB 1.1(full-speed), and USB 2.0 (high-speed) data transfer rates
■ Supports USB hot-swap, Plug-and-Play, and suspend/resume features
■ No driver installation needed for the extender, the USB driver is installed automatically by the operating system
■ Metal housing for better RF shielding, efficient cooling, dependable performance
■ Distributes HDMI video and audio from a single source to up to 2 HDMI displays simultaneously while maintaining signal quality
■ Compliant with HDMI 2.0 and HDCP 2.2
■ Supports 18Gbps bandwidth
■ Supports up to 4K (3840x2160) @60Hz (YUV 4:4:4 8-bit), HDR 4K (3840x2160) @60Hz (YUV 4:2:0 10-bit), 3D, xvYCC, x.v.Color & Deep Color
■ Supports Dolby Digital, DTS-HD and Dolby TrueHD audio
■ Resolution downscaling feature detects and configures the video resolution automatically according to the capabilities of each connected monitor
■ Allows simultaneous 4K and 1080P output. Supports simultaneous mixed 4K and 1080p display outputs. *See Notes below for limitations
■ EDID and firmware management feature for maximum compatibility now and into the future, offers widest range of monitor/display/TV support from either pre-programmed EDID or EDID learning from the connected displays. Firmware upgradeable (via Mini USB port) for expanded compatibility
■ Low heat generation with sturdy metal housing provides excellent heat dissipation, durability, and minimizes EMI/RFI noise interference. Low heat generation and ESD protection to guarantee stability and reliable performance
*Notes:
- Down scaling to 720p and 480p is not supported
- YUV 4:2:2 down scaling is not supported
- Frame rate conversion (e.g., 60Hz to 24Hz) is not supported
- [email protected] monitors will display in [email protected] when the source content is [email protected]
- The Splitter can bypass 4K HDR data content but cannot process it to make 4K HDR content fit 1080p proportionally
■ 1 meter USB-C (male) to USB-C (male) cable provides fast charging and high-speed data syncing between power charging adapters, desktops, laptops, tablets or smartphone devices equipped with USB-C connection
■ Supports USB Power Delivery (PD) power up to 20V/5A (100W) to charge your laptop and other USB-C powered devices
■ Supports USB 3.1 data transfer rates up to 10Gbps
■ Supports DisplayPort Alternate mode transmission up to [email protected] resolution to connect an extra UHD display
■ USB-C connector allows reversible plug-in connection so there is no possibility of plugging in the wrong direction
■ Supports USB 3.1 10Gbps, USB Power Delivery, and DisplayPort Alternate mode transmissions via Thunderbolt 3 enabled USB-C ports
Note: This cable does not support native Thunderbolt devices through Thunderbolt 3 USB-C ports
■ Solid copper coaxial cable with strong PVC molding
■ USB-C (male) to USB-C (male) cable provides fast charging and high-speed data syncing between power charging adapters, desktops, laptops, tablets or smartphone devices equipped with USB-C connection
■ Supports USB Power Delivery (PD) power up to 20V/3A (60W) to charge your laptop and other USB-C powered devices
■ Supports USB 3.1 data transfer rates up to 10Gbps
■ Supports DisplayPort Alternate mode transmission up to [email protected] resolution to connect an extra UHD display
■ USB-C connector allows reversible plug-in connection so there is no possibility of plugging in the wrong direction
■ Supports USB 3.1 10Gbps, USB Power Delivery, and DisplayPort Alternate mode transmissions via Thunderbolt 3 enabled USB-C ports
Note: This cable does not support native Thunderbolt devices through Thunderbolt 3 USB-C ports
■ Solid copper coaxial cable with strong PVC molding
■ USB-C (male) to USB-C (male) cable provides fast charging and high-speed data syncing between power charging adapters, desktops, laptops, tablets or smartphone devices equipped with USB-C connection
■ Supports USB Power Delivery (PD) power up to 20V/3A (60W) to charge your laptop and other USB-C powered devices
■ Supports USB 3.1 data transfer rates up to 5Gbps
■ Supports DisplayPort Alternate mode transmission up to [email protected] resolution to connect an extra UHD display
■ USB-C connector allows reversible plug-in connection so there is no possibility of plugging in the wrong direction
■ Supports USB 3.1 5Gbps, USB Power Delivery, and DisplayPort Alternate mode transmissions via Thunderbolt 3 enabled USB-C ports
Note: This cable does not support native Thunderbolt devices through Thunderbolt 3 USB-C ports
■ Solid copper coaxial cable with strong PVC molding
■ Easily transforms a DisplayPort Alt mode enabled USB Type-C port or Thunderbolt 3 port into a HDMI output to connect to a HDMI display
Note: The USB-C source connection must contain DisplayPort video/audio signal, aka DisplayPort Alternate Mode/DisplayPort Alt Mode, in order for the audio and video signals to pass through to the HDMI adapter
■ Supports HDMI audio and video signals with resolutions of 720p HD, 1080p Full HD and up to [email protected] UHD
■ Features USB-C reversible plug design, non-directional plug-in orientation, you will always plug-in the USB-C connector on the first try
■ USB-C with DisplayPort Alt Mode or Thunderbolt 3 technology is available with many computers such as 2016 MacBook Pro, the 2015 MacBook, Google Chromebook Pixel, and many more
■ Plug-n-Play, no driver installation and no external power adapter required
■ Easily transforms a DisplayPort Alt mode enabled USB Type-C port or Thunderbolt 3 port into a DisplayPort output to connect to a DisplayPort display
Note:The USB-C source connection must contain DisplayPort video/audio signal, aka DisplayPort Alternate/DisplayPort Alt mode, in order for the audio and video signals to pass through to the DisplayPort adapter
■ Supports DisplayPort audio and video signals with resolutions of 720p HD, 1080p Full HD and up to [email protected] UHD
■ Features USB-C reversible plug design, non-directional plug-in orientation, you will always plug-in the USB-C connector on the first try
■ USB-C with DisplayPort Alt Mode or Thunderbolt 3 technology is available with many computers such as 2016 MacBook Pro, the 2015 MacBook, Google Chromebook Pixel, and many more
■ Plug-n-Play, no driver installation and no external power adapter required
■ Easily transforms a DisplayPort Alt mode enabled USB Type-C port or Thunderbolt 3 port into a HDMI output to connect to a HDMI display
Note:The USB-C source connection must contain DisplayPort video/audio signal, aka DisplayPort Alternate Mode/DisplayPort Alt Mode, in order for the audio and video signals to pass through to the HDMI adapter
■ Supports HDMI audio and video signals with resolutions of 720p HD, 1080p Full HD and up to [email protected] UHD
■ Features USB-C reversible plug design, non-directional plug-in orientation, you will always plug-in the USB-C connector on the first try
■ USB-C with DisplayPort Alt Mode or Thunderbolt 3 technology is available with many computers such as 2016 MacBook Pro, the 2015 MacBook, Google Chromebook Pixel, and many more
■ Plug-n-Play, no driver installation and no external power adapter required
■ Premium Quality HDMI Cable - Supports Ultra High Definition video resolution up to 8K
■ HDMI 2.1 Standard - Compatible with HDMI 2.1, backwards compatible with earlier versions
■ Triple-shielding cable - Effectively reduces EMI interference for maximum video performance and prevention of signal loss
■ Gold-plated connectors - Provides superior conductivity and delivers flawless HD A/V signals
■ Pure copper wires - Prevents signal degradation and provides optimal signal quality
■ Advanced features - Supports 4K HDR, Ethernet, Audio Return Channel and 3D technologies
■ Premium Quality HDMI Cable - Supports Ultra High Definition video resolution up to 8K
■ HDMI 2.1 Standard - Compatible with HDMI 2.1, backwards compatible with earlier versions
■ Triple-shielding cable - Effectively reduces EMI interference for maximum video performance and prevention of signal loss
■ Gold-plated connectors - Provides superior conductivity and delivers flawless HD A/V signals
■ Pure copper wires - Prevents signal degradation and provides optimal signal quality
■ Advanced features - Supports 4K HDR, Ethernet, Audio Return Channel and 3D technologies
